What is a Draw Plate?

by Judy Ellis, Wire-Sculpture.com

Tool of the Week for June 23, 2014

This week’s Featured Tool is the Draw Plate.

Today I thougth I’d feature a very basic but extremely use tool are a must-have tool for wire jewelry artists – The Draw Plate. I’ve featured two versions below that we carry on the Wire-Sculpture website in our Tools section – the Wooden Draw Plates, along with descriptions ofthem and a littel bit abou how you use them.

If you are not familiar with Draw Plates, then this might be a good introduction to them for you. If you are familiar with how they work, then this hopefully will be a great refresher. Let’s take a look at them.

What is a “Draw Plate”?

Wooden draw plates are a key tool in weaving chain, such as Viking Knit Chain, because the wood gently reduces the woven wire.

This handy drawplate is designed for reducing soft chain or woven chain like Viking Knit Chain.Made of hard boxwood with 12 smooth holes from 1.2mm to 6.5mm.

Simply pull your chain through consecutively smaller holes in the draw plate, reducing the size of the chain.

Note that on one side of the block, the holes are slightly chamfered, or beveled, to facilitate pulling the wire through.

User may put the “tang” of the block into a vise, or hold it by hand. Measures 3 1/2 x 2/ 1/2 x 3/4 inches.

This handy tool is designed for reducing soft chain or woven chain. A larger 12-hole drawplate with an easy-to-use handleHoles range in size from 3mm to 14mm in diameter, increasing in 1mm increments. Beveled, or chamfered, holes make this great for Viking Knit Chain and other large chain.

Measures 8 1/2 x 2 3/8 x 3/8 inches.

Metal draw plates are different. (We don’t currently carry Metal Draw Plates, but you can find them HERE on our sister site, JewelryTools.com) You can use a metal draw plate to take round wire and reduce its diameter, and even shape it into half round, triangle, or square wire, just like the wire mills do!



Jewelry draw plates will transform your wire working in creative, new ways!

If you would like to know more about Viking Knit Chain – take a look at our Coiling and Weaving DVD Series Part 3. It walks you step-by-step through several Viking Knit Chain projects.

If you are interested in learning more about Jewelry Making, CLICK HERE to sign up for our FREE JEWELRY MAKING PATTERNS.



Happy Wrapping!



Click to Receive Daily Tips by Email

Easy Egyptian Coil

by Judy Ellis, Wire-Sculpture.com

Wire Wrapping Tutorial May 14, 2014

Easy Egyptian Coil

I thought today I would share with you a quick tutorial about how to make an Egyptian Coil. It’s easy and versatile. I hope you enjoy it!

Tips: Cut all your pieces of wire the same length. Pictured: 20 gauge wire, cut into 6 inch lengths.

When you make your coils, it’s important that they are all consistent. Do the first one, and get it to the point that both ends are coiled, then set it aside and use that one to measure and compare against all the others you do.

Step 1: Put a loop at each end of the wire.

coil2

coil1

Step 2: Use your pliers to slowly coil the wire at each end.

coil3

When you’re done you should have a piece like the photo below.

coil4

Step 3: Bend it in half one direction.

coil5

Step 4: Then bend it the other way for a finished single link.

coil6

Step 5: You can thread multiple links through each other to make the desired length that you want.

coil7



Finished Bracelet

coil8

*If you want the coils to overlap, bend the loop over just at or below the height of the coils. If the tail is too long the gap will be big.

If you’d like to practice your coils and spirals before attempting this Egyptian Coil design, take a look at our FREE pattern called Best Ever Coils.  Then if you’d like to learn more about working with wire – why not take a look at our Coiling and Weaving DVD Series.

CLICK HERE to order your Wire Supplies today!



Happy Wrapping!

Judy Ellis





Original Tutorial by Marie Cristine

Click to Receive Daily Tips by Email

Twisting 101

by Judy Ellis, Wire-Sculpture.com



Tip for March 28, 2014

Wire Twisting 101- Jewelry Making Tools

Twisted wire can add style, dimension, and elegance, flash or fun to a wire jewelry design. Sometimes twisted wire is a major player, placed where it is to be seen and sometimes it is added in obscure places to add interest to a design such as within the sides of a framed cabochon.

I receive questions from those who are a bit confused as to how to twist wire, what to twist and when to use it, so my hope is that this article enables you to have more fun using twisted wires in your jewelry designs.

Let’s begin by looking at a variety of ‘wire twisters’, and how to use them.

1. Wire-twisting pliers:

They are basically a pair of large, heavier pliers with an attached pin vise that has a spring-loaded handle.

How to use it:

  1. After cutting the desired length of wire to be twisted, one end is tightly secured to a solid surface such as winding it around a nail on a bench or a wall, (or having another person hold the end firmly in a heavy pair of flat-nose pliers).
  2. The operation is to then insert the other end of the wire(s) through a hole at the back of the plier’s jaws and then into the end of the pin vise.
  3. After locking the wires tightly into the pin vise, the round knob at the end of the pin vise is pulled out and let go, causing the spring mechanism within the pin vise unit to twist the wire(s). It can be continuously pulled and released until the wire is twisted to satisfaction, and would be best used for lengths of wire18-inches and longer.
  4. After the desired twist has been achieved, open the pin vise to release the wire and pull it out of the pliers, then unhook the wire from the nail or other secured end. Yes, these pliers can be used to twist either a single or most multiple wire combinations.

2. Automatic Wire Twister:

A cordless power screwdriver is a small, compact unit that can be used to twist either a single or most multiple wire combinations easily. The Automatic wire twister has twice the power of most cordless screwdrivers. This automatic wire twister is approximately 7.5 inches tall, has 4.8 volts of power, and spins at 400rpm. Twist almost any size wire at twice the speed!

The three-prong chuck is included, so you don’t need to order an extra twister head–it’s all here. A complete wire twisting package with no other attachments needed. Weight is 1.5 lbs.

Please note: This tool comes with a rechargable battery pack and A/C Charge Adapter. To recharge the battery pack, you must plug the adapter into a 120 A/C outlet, which is standard for the US. If your country uses another voltage, you may need an adapter for this tool.

How to use it:

  1. Place the end(s) of the length of wire(s) to be twisted into the chuck and spin the chuck tightly closed around the wire(s).
  2. Hold the opposite end of the wire firmly in a pair of flat-nose pliers and push the button in either the forward or the reverse direction and twist until the desired effect has been obtained.
  3. Open the chuck and release the wire. (Having the option of either forward or reverse is nice when planning wire designs.)
  4. Most power screwdrivers include an A/C adaptor that can be used to charge the unit for use without electricity. The A/C adaptor is also a nice feature as when the charged power has run out, the unit can still be used while plugged into an electric source and charging. Yes, a power screwdriver can be used to twist really long lengths of wire, gauges 12 and smaller.

3. Pin Vises: There are two types.

Swivel Head Pin Vise

Double Ended Pin Vise

How to use them:

Each is used in the same manner.

  1. Twist one of the heads to open the inset jaws and then insert the end of a single piece of wire, (or two or three small gauged wires), into the center and twist the head tightly closed around the wire(s).
  2. Hold the opposite end(s) of the wire(s) firmly with flat-nose pliers and twist the pin vise with the other hand until the wire is twisted to the desired look.
  3. Then twist the head open to release the wire.

These units are most often used to twist shorter lengths of wire, from ¼-inch to 12-inches. Each of these two pin vise styles can be used to twist separate segments on the same wire.

Holding Wire While Twisting:

Although a pair of chain-nose pliers can be used, I prefer to use flat-nose pliers to hold the opposite end of the wire. The larger surface area inside the jaws of a flat-nose give more stability and you do not have to hold them in a ‘death grip’, thus preventing possible damage to your hand or wrist.

How to properly twist:

  1. Place about 1/8-inch of the wire end into the jaws of flat-nose pliers, about mid-way down the jaw.
  2. Hold the pliers so they are vertical to the horizontal position of the wire, grip firmly and hold the wire so it is just tautly and twist away! If you hear a ‘clicking’ noise coming from the flat-nose end, you are not holding the wire tightly enough and the wire is turning within the flats.

What about wire?

We receive a lot of questions with regards to confusion about the sizes, shapes and tempers of wire to twist or not to twist. Here are a few facts to remember:

• Twisting any temper of wire will harden it!

• The more tightly any wire is twisted, the thinner and weaker the wire becomes; therefore take care when working a tightly twisted wire using complicated techniques.

Twisting Square Wire:

• When an individual square wire is twisted, the resulting appearance is similar to a diamond cut chain, which is referred to as a ‘bead’.

• Although two individually twisted square wires can then be twisted together,due to the difficulty in getting each individually twisted to the same ‘bead’, the result will more than likely be a looser twist as the two twisted wires will seem to repel each other.

Twisting Round Wire:

• A single round wire cannot be twisted to get a ‘party streamer’ or coiled appearance.

• Two or more round wires can be put into a wire twister and twisted together.

• Round wire can be twisted around a square wire.

Twisting Half-round Wire:

• Half-round wire can be twisted around a square or a round wire.

• Half-round wire can be twisted individually.

For more detailed instruction – Check out our complete line of Instructional DVDS to get you started!

I hope this answers a few of the many questions about twisting wire. If you’re a beginner, don’t be afraid to try it.

Happy Twisting!

Click to Receive Daily Tips by Email



Creating with Metal

by Judy Ellis, Wire-Sculpture.com



Jewelry Resource for March 19, 2014

Creating with Metal

Are you interested in learning more about how to make metal jewelry? Or maybe you have some experience, but want some additional practice… In either case, in our Metalworking 101 DVD Series Patti Bullard walks you step-by-step through 6 projects that are not only fun to create, but beautiful. Today I wanted to offer you a peek at some of the projects that Patti creates. I know you’ll love them!

Metalworking 101 DVD Series Projects

DVD 1: Earring EssentialsFunctional Zipper Pulls

Make 2 different pairs of earrings in Earring Essentials. Learn to solder post earrings and make ear hooks, explore dapping and texturing, and make a wire wrapped dangle. You’ll learn all the basics of soldering, including pickling, quenching, torch safety, and Patti’s little tricks to make soldering fun and easy.

DVD 2: Geometric Links Bracelet

Functional Zipper Pulls

Shape heavy-gauge wire around Wubbers® mandrel pliers and make perfect soldered joins while making this Geometric Links Bracelet. Discover Patti’s satin-smooth finish secret and find the best tool for the job. You’ll create a dangly, jangly bracelet that is a great gift and will help you practice soldering.

DVD 3: Mix & Match Stacking Rings

Mix & Match Stacking Rings

Use special wire and the soldering techniques we’ve practiced to create your own Mix & Match Stacking Rings. Discover how to solder a ring, attach a bezel cup, and set a cabochon in the bezel. Plus tips on finishing the rings and applying patina.

DVD 4: Mixed Metal Collage Pendant

Mixed Metal Collage Penant

Step into an art & composition cold connections workshop with this Mixed Metal Collage Pendant. Discover what makes a collage pendant interesting, learn to punch and rivet metal, and make a one-of-a-kind bail. Then turn on your flame to paint with heat patinas! Includes a tracing example and a composition guide.

DVD 5: Discover Open Back Bezels

Open Back Bezels

Use pattern wire and soldering techniques to create an open back bezel, which you can use to make earrings and pendants. Fill an open back bezel with EnCapture Concrete to embed your treasures, and discover how to add color to the background. Exploring Open Back Bezels will open your eyes to all the possibilities!

DVD 6: Twinkle Star Bracelet

Twinkle Star Bracelet

Stamp and decorate this mixed metal Twinkle Star Bracelet to create a charming link bracelet. Solder and cold connect to create a piece that fits the wrist perfectly and showcases your mastery of soldering techniques.

Do you want to know more?

A little bit about Patti: Patti Bullard is a jewelry instructor, the inventor of Wubbers® pliers, and a lifelong artist. Patti has taught wire working and metal-smithing across the United States since 2004, and loves sharing her enthusiasm and techniques with others. Patti’s experience in many forms of jewelry creation has given her a unique insight into the best tools and creation methods, and she enjoys teaching others how to craft unique jewelry pieces. You’ll be amazed how easy Patti makes soldering!

Pick up your own Metalworking 101 DVD Series today!

Metalworking 101 DVDS

Happy Metalworking!

Click to Receive Daily Tips by Email

The 5-Minute, 5-Things Spiral Ring

by Judy Ellis, Wire-Sculpture.com

Live from Tucson 2014

Tip for February 5, 2014

Tip Guide to Tucson!

The 5-Minute, 5-Things Spiral Ring By Kate Richbourg

I made this ring at the demo booth at the Tucson Gem Show. Heather from Jewelry Tools came over with a camera and said “Wire tutorial for our blog… Ready? Go!” I am always up for a quick and easy and off-the-cuff project. The result is this fast and stylish wire ring. Don’t worry that your spiral may not look like mine. Creativity is the key here. Try it with round wire in a different gauge, tighter or looser spirals or more wire for a bigger spiral. Create and have fun.

The five things you need:

The five steps:

1. Cut 1 ft. of wire and wrap it twice around the ring mandrel at your preferred with the ends crossing on the top with tails of equal length.

2. Use your hands to pull one wire to the left about a quarter way around. The wires will start to form an s-shape to make the interior of the spiral. Repeat with the second tail. Switch between each tail of wire, forming the spiral and keeping it flat. Stop when you have about 1/2″ tails remaining on both wires. Be as free-form as you like and don’t worry about getting a perfect spiral. A free-form spiral looks great with this design.

3. Use chain nose pliers to wrap the tails around the shank of the ring on each side. 2-4 wraps per side will secure the spiral.

4. Place the ring back on the ring mandrel and adjust the shape.

5. Add a patina to the ring using Liver of Sulfur and polish with a pro polish pad. Slip it on your finger and admire!

To learn more about Kate Richbourg and see the amazing classes that she’s teaching in Tucson, CLICK HERE



Now we want to hear from you! What neat tips do you have for a great Tucson trip?

Click to Receive Daily Tips by Email
